Strut channel (slotted channel / Unistrut type) is the framing backbone behind every cable tray support, pipe support and equipment frame. We supply channel, fittings, nuts, clamps and concrete insert profiles as one matched system.
A slotted strut system lets installers adjust support positions without drilling, which is why it replaced welded brackets in most mechanical and electrical installations. Our channel range covers 41×21, 41×41, 41×62 and back-to-back profiles in 1.5 / 2.0 / 2.5 mm gauges.
Every profile is supplied with a full hardware range — spring and no-spring channel nuts, hexagon and carriage bolts, washers, beam clamps, corner angles, splices, closures and threaded rod — so the support system arrives complete and ready to assemble.
Standard stock range; custom sizes, slot patterns and hole layouts produced on request.
| Profile sizes | 41 × 21 mm, 41 × 41 mm, 41 × 62 mm, back-to-back welded pairs |
| Thickness | 1.5 / 2.0 / 2.5 mm (custom gauges on request) |
| Slot pattern | Longitudinal slot with standard 22 mm spacing punched along the full length |
| Standard length | 3000 / 4000 / 6000 mm; concrete insert 3000 mm |
| Material | Pre-galvanized steel, hot-dip galvanized steel, SS304, SS316L, aluminium |
| Fittings range | 2/3/4-hole fittings B1062–B1064, corner bends, angle brackets, T and L connections, splices |
| Hardware | Channel nuts M6–M12 (short spring / long spring / no spring), beam clamps, drop-in anchors, threaded rod M6–M12 |
| Standards | Manufactured to metric dimensions for global interchangeability; load data available per profile |
Click through to the complete catalogue or send us your drawing for a matched quotation.
We produce to drawing — custom width, height, thickness, slot pattern and finish within 15–25 days.
Metric slot geometry means our channel, nuts and fittings work with other standard systems already on your site.
Nuts, bolts, washers, beam clamps and anchors are sourced together, avoiding multiple suppliers with mismatched specifications.
Channel is bundled by length and hardware can be packed per-project in labelled cartons to speed site handling.
Pre-galvanized, hot-dip and stainless versions with coating thickness stated, suitable for dry interior through to marine environments.
Complete your cable management package with one shipment and one point of responsibility.
Not sure which type or thickness suits your load? Read the Cable Tray Buying Guide — covers type selection, finish comparison, sizing rules and international standards.
Yes, both sizes are standard along with 41×62 back-to-back versions, in pre-galvanized, hot-dip galvanized and stainless steel.
Yes. Short spring, long spring and no-spring channel nuts in M6 to M12 are stocked, plus matching hex screws, nuts and washers.
We supply cast-in concrete insert profiles for 41×21 and 41×41 with foam filler to prevent concrete ingress, used in precast and tunnel construction.
Hot-dip galvanized is the standard recommendation for outdoor and industrial environments; SS316 is specified for coastal or chemical exposure.
Mixed cartons of fittings and fasteners can be combined with channel orders; there is no separate MOQ per item within a consolidated shipment.
Include width, height, thickness, finish, length and quantity for the fastest quote. Drawings and BOQ files welcome.
